Punched window Systems AT 730 HI-S

For a variety of applications, a wide range of profiles available. All usual fittings such as side hung, turn-and-tilt and tilt fittings can be installed in the systems AT 730 HI-S. System accessories are largely compatible with other AKOTHERM systems. Corner connections can be pressed or pinned together with corner brackets.

Your benefits:

• Maximum compatibility with existing AKOTHERM systems
• Security through burglary resistance
• High thermal insulation
• Approved as NSHEV element
• Proven and established manufacturing technology

Tech. features

Heat transfer
EN ISO 10077-2: Uf -value = up to 1,7 W/(m²K)

Air permeability
EN 12207: Class 4

Water tightness
EN 12208: Class E 1050

Sound insulation
DIN EN ISO 140 Part 3: up to RW = 47 dB

Glazing
Filling thickness from 20 to 62 mm

Installation depth
Frame 70 mm, Casement 80 mm, Glazing bar 70 mm

Credentials:

2D sections:
